Power and cooling part numbers (Model 983)

Table 1. Start here, rack power and cooling FRUs (Model 983)
Part name Reference
Local remote switch card Figure 1, Figure 2, Figure 3
Management enclosure fan assembly Figure 1, Figure 2, Table 3
Management enclosure power supply Figure 1, Figure 2, Figure 4
RPC card Figure 1, Table 2, Figure 5, Figure 6
UPS Figure 1, Figure 7
UPS battery Figure 1, Figure 7
UPS network card Figure 1, Figure 8
All other parts (Find the appropriate figure below)
Figure 1. Storage facility power locations
Storage controller module (enclosures shown)

Management Enclosure FRUs

Figure 2. Management enclosure locations (Model 983)
Management enclosure locations
Figure 3. Local remote switch card locations (Model 983)
Local remote switch card locations (Model 983)
Table 2. Local remote switch card FRU and cables (Model 983)
Location code Part name Part number
C6 Local remote switch card 02AM855
C6-J2 Local remote cable 02AM526
C6-J3 Local remote cable 02AM527
C6-J4 LED cable assembly 02AM556
Table 3. Management enclosure fan assembly FRU
Location code Part name Part number
A1
A2		 Management enclosure fan assembly 02AN603
Figure 4. Management enclosure power supply locations
Management enclosure power supply locations
Table 4. Management enclosure power supply FRU and cables (Model 983)
Location code Part name Part number
E31 Management enclosure power supply 02AM882
E32 Management enclosure power supply 02AM882
E31-J1 RPC power cable 02AM524
E32-J1 RPC power cable 02AM524
E31-J2 RPC power cable 02AM525
E32-J2 RPC power cable 02AM525
E31-J3 Management enclosure 12 V power distribution cable 02AM523
E32-J3 Management enclosure 12 V power distribution cable 02AM523
Figure 5. Location codes for the RPC card (Model 983), front view
Location codes for the RPC card (Model 983), front view
Figure 6. Location codes for the RPC card (Model 983), rear view
RPC card rear connectors J2xx
Table 5. RPC card C1 FRU and cables (Model 983)
Location code Part name Part number
C1 RPC card 02AM465
C1-J1 RPC to RPC comm cable 02AM528
C1-J2 RPC power cable 02AM524
C1-J3 Local remote cable 02AM526
C1-J201 Not used
C1-J202 Not used
C1-J203 RPC card to CEC enclosure serial cable (RPC-1 to upper CEC) 02AN259
C1-J204 RPC card to CEC enclosure I2C cable (RPC-1 to upper CEC) 02AN255
C1-J205 RPC card to CEC enclosure serial cable (RPC-1 to lower CEC) 02AN260
C1-J206 RPC card to CEC enclosure I2C cable (RPC-1 to lower CEC) 02AN256
C1-J207 Serial cable to upper UPS 02AN265
C1-J208 Power control network (PCN) cable 02AN466
Table 6. RPC card C2 FRU and cables (Model 983)
Location code Part name Part number
C2 RPC card 02AM465
C2-J1 RPC to RPC comm cable 02AM528
C2-J2 RPC power cable 02AM525
C2-J3 Local remote cable 02AM527
C2-J201 Not used
C2-J202 Not used
C2-J203 RPC card to CEC enclosure serial cable (RPC-2 to upper CEC) 02AN261
C2-J204 RPC card to CEC enclosure I2C cable (RPC-2 to upper CEC) 02AN257
C2-J205 RPC card to CEC enclosure serial cable (RPC-2 to lower CEC) 02AN262
C2-J206 RPC card to CEC enclosure I2C cable (RPC-2 to lower CEC) 02AN258
C2-J207 Serial cable to lower UPS 02AN266
C2-J208 Power control network (PCN) cable 02AN467
Figure 7. Location codes for the UPS (Model 983), front view
Location codes for the UPS (Model 983), front view
Figure 8. Location codes for the UPS (Model 983), rear view
Location codes for the UPS (Model 983), rear view
Table 7. UPS FRUs (Model 983)
Location Part name Part number
E61
E62		 UPS 02AM964
E61-E1
E62-E1		 UPS battery 02AM968
E61-C1
E62-C1		 UPS network card 02AN340
Table 8. UPS (E61, upper) cable FRUs (Model 983)
Location Part name Part number
E61-C1-J1 Ethernet cable 02AN241
E61-C1-J2 Not used
E61-J3 Power cable 02AN272
E61-J4 Power cable 02AN272
E61-J5 Power cable 02AN272
E61-J6 Power cable 02AN272
E61-J7 Power cable 02AN272
E61-J8 Power cable 02AN272
E61-J9 Not used
E61-J10 Mainline power cable See Table 10.
E61-J11 Not used
E61-J12 Not used
E61-J13 Serial cable to RPC C1 02AN265
E61-J14 Not used
Table 9. UPS (E62, lower) cable FRUs (Model 983)
Location Part name Part number
E62-C1-J1 Ethernet cable 02AN246
E62-C1-J2 Not used
E62-J3 Power cable 02AN271
E62-J4 Power cable 02AN271
E62-J5 Power cable 02AN271
E62-J6 Power cable 02AN271
E62-J7 Power cable 02AN271
E62-J8 Power cable 02AN271
E62-J9 Not used
E62-J10 Mainline power cable See Table 10.
E62-J11 Not used
E62-J12 Not used
E62-J13 Serial cable to RPC C2 02AN266
E62-J14 Not used
Table 10. Mainline power cables (Model 983)
Location Part name Part number
E6x-J10 FC 1021 - power cord, C19 to NEMA L6-20P (US, Canada) 4.3 m 39M5279
E6x-J10 FC 1022 - power cord, C19 to CEE 7 VII 16A (EMEA) 4.3 m 39M5283
E6x-J10 FC 1023 - power cord, C19 to SANS 164 16A (South Africa) 4.3 m 39M5291
E6x-J10 FC 1024 - power cord, C19 to CEI 23-16 (Italy) 4.3 m 39M5299
E6x-J10 FC 1025 - power cord, C19 to RS 3720DP (US, Canada) 4.3 m 39M5319
E6x-J10 FC 1026 - power cord, C19 to IEC309 (P+N+G) 16A (Denmark) 4.3 m 39M5323
E6x-J10 FC 1027 - power cord, C19 to AS/NZS 3112 15A (Australia, New Zealand) 4.3 m 39M5331
E6x-J10 FC 1028 - power cord, C19 to JIS C 8303 6-20P 15A (Japan) 4.3 m 39M5335
E6x-J10 FC 1029 - power cord, C19 to C20 16A (UPS to rack PDU) 2.5 m 39M5389
E6x-J10 FC 1030 - power cord, C19 to IRAM 2073 16A (Argentina) 4.3 m 39M5343
E6x-J10 FC 1031 - power cord, C19 to KSC 8305 16A (Korea) 4.3 m 39M5549
E6x-J10 FC 1032 - power cord, C19 to IS 6538 16A (India) 4.3 m 39M5397
E6x-J10 FC 1033 - power cord, C19 to CH2-16P (China) 4.3 m 39M5355
E6x-J10 FC 1034 - power cord, C19 to NBR 14136 16A (Brazil) 4.3 m 39M5536
E6x-J10 FC 1035 - power cord, C19 to CNS 10917-3 15A (Taiwan) 4.3 m 39M5367
E6x-J10 FC 1036 - power cord, C19 to SI 32 16A (Israel) 4.3 m 39M5311
E6x-J10 FC 1037 - power cord, C19 to SEV 1011 T23 16A (Switzerland) 4.3 m 39M5442
